Relying on the core resources of HKC LCD panel, the display solution business has a first-mover advantage in the research and development of screen technology and trend products, and has realized the product coverage of full scenes such as esports, ultra-widescreen, high score and curved surface, and has been laid out in the direction of 8K high resolution, MiniLED backlight, OLED, 240Hz+ high refresh rate, high color gamut, etc. To provide partners with comprehensive, worry free, high-quality display solutions
| Dimension | Screen scale | Form | Panel type | Resolution | Refresh rate | luminance | Response time | Colour gamut | Display color | HDR | Port | Input power supply | Stand/Base |
| 19.5 | 16:9 | plane | TN | 1600*900 | 60 Hertz | 220 Nit | 5 ms | 68% NTSC | N/A | N/A | ①VGA；②VGA+HDMIDMI(1.4); ③VGA+HDMIDMI+Audio outputport+megaphone | Direct current 12V/2A | Simple style |
| 21.5 | 16:9 | plane | VA | 1920*1080 | 75 Hertz | 220 Nit | GTG 5 ms(W/ OD) | 68% NTSC | N/A | N/A | ①VGA；②VGA+HDMIDMI(1.4); ③VGA+HDMIDMI+Audio outputport+megaphone | Direct current 12V/2A | Simple style |
| 23.8 | 16:9 | plane | VA/IPS | 1920*1080 | 75 Hertz | 220 Nit | GTG 5 ms(W/ OD) | 68% NTSC | N/A | N/A | ①VGA；②VGA+HDMIDMI(1.4); ③VGA+HDMIDMI+Audio outputport+megaphone | Direct current 12V/2A | Simple style |
| 23.8 | 16:9 | plane | VA/IPS | 1920*1080 | 75 Hertz/100 Hertz | 250 Nit | GTG 5 ms(W/ OD) | 72% NTSC | N/A | N/A | ①VGA+HDMIDMI(1.4); ② VGA+HDMIDMI+Audio outputport+megaphone | Simple style | Simple style |
| 23.8 | 16:9 | plane | VA/IPS | 1920*1080 | 75 Hertz/100 Hertz | 250 Nit | 5 ms(W/ OD) | 72% NTSC | N/A | N/A | VGA+HDMIDMI(1.4) HDMI+revealport | adapter | Simple style |
| 27 | 16:9 | plane | IPS | 1920*1080 | 75 Hertz/100 Hertz | 250 Nit | 5 ms(W/ OD) | 72% NTSC | N/A | N/A | VGA+HDMIDMI(1.4) HDMI+revealport | adapter | Simple style |
| 27 | 16:9 | plane | IPS | 2560*1440 | 75 Hertz/100 Hertz | 250 Nit | GTG 5 ms(W/ OD) | 72% NTSC | N/A | N/A | HDMI(1.4)+HDMI(1.4)+revealport | adapter | Simple style |
| 21.45 | 16:9 | plane | VA | 1920*1080 | 75 Hertz/100 Hertz | 250 Nit | GTG 5 ms(W/ OD) | 72% NTSC | N/A | N/A | ①VGA+HDMIDMI(1.4); ②VGA+HDMIDMI+Audio outputport+megaphone(Optional); ③VGA+HDMIDMI+revealport+A(I/O)+megaphone(Optional); ④HDMI+HDMI+revealport+A(I/O)+megaphone(Optional); | adapter/Built-in power supply | Simple style |
| 21.5 | 16:9 | plane | VA | 1920*1080 | 75 Hertz | 250 Nit | GTG 5 ms(W/ OD) | 72% NTSC | N/A | N/A | ①VGA+HDMIDMI(1.4); ②VGA+HDMIDMI+Audio outputport+megaphone(Optional); ③VGA+HDMIDMI+revealport+A(I/O)+megaphone(Optional); ④HDMI+HDMI+revealport+A(I/O)+megaphone(Optional); | adapter/Built-in power supply | Simple style |
| 23.8 | 16:9 | plane | VA/IPS | 1920*1080 | 75 Hertz/100 Hertz | 250 Nit | GTG 5 ms(W/ OD) | 72% NTSC | N/A | N/A | ①VGA+HDMIDMI(1.4); ②VGA+HDMIDMI+Audio outputport+megaphone(Optional); ③VGA+HDMIDMI+revealport+A(I/O)+megaphone(Optional); ④HDMI+HDMI+revealport+A(I/O)+megaphone(Optional); | adapter/Built-in power supply | Simple style |
| 23.8 | 16:9 | plane | IPS | 2560*1440 | 75 Hertz | 250 Nit | GTG 5 ms(W/ OD) | 72% NTSC | N/A | N/A | ①VGA+HDMIDMI(1.4); ②VGA+HDMIDMI+Audio outputport+megaphone(Optional); ③VGA+HDMIDMI+revealport+A(I/O)+megaphone(Optional); ④HDMI+HDMI+revealport+A(I/O)+megaphone(Optional); | Built-in power supply | Simple style |
| 27 | 16:9 | plane | VA/IPS | 1920*1080 | 75 Hertz/100 Hertz | 250 Nit | GTG 5 ms(W/ OD) | 72% NTSC | N/A | N/A | ①VGA+HDMIDMI(1.4); ②VGA+HDMIDMI+Audio outputport+megaphone(Optional); ③VGA+HDMIDMI+revealport+A(I/O)+megaphone(Optional); ④HDMI+HDMI+revealport+A(I/O)+megaphone(Optional); | adapter/Built-in power supply | Simple style |
| 27 | 16:9 | plane | VA/IPS | 2560*1440 | 75 Hertz | 250 Nit | GTG 5 ms(W/ OD) | 72% NTSC | N/A | N/A | ①VGA+HDMIDMI(1.4); ②VGA+HDMIDMI+Audio outputport+megaphone(Optional); ③VGA+HDMIDMI+revealport+A(I/O)+megaphone(Optional); ④HDMI+HDMI+revealport+A(I/O)+megaphone(Optional); | adapter/Built-in power supply | Simple style |
| 23.8 | 16:9 | plane | IPS | 1920*1080 | 75 Hertz/100 Hertz | 250 Nit | GTG 14 ms/7 ms(W/ OD) | 72% NTSC | N/A | N/A | VGA+HDMIDMI(1.4)/HDMI+revealport | adapter | Simple style |
| 27 | 16:9 | plane | IPS | 1920*1080 | 75 Hertz/100 Hertz | 250 Nit | GTG 14 ms/7 ms(W/ OD) | 72% NTSC | N/A | N/A | VGA+HDMIDMI(1.4)/HDMI+revealport | adapter | Simple style |
| 27 | 16:9 | plane | IPS | 2560*1440 | 75 Hertz/100 Hertz | 250 Nit | GTG 7 ms(W/ OD) | ADOBE 95% | N/A | N/A | HDMI(1.4)*2)+revealport | adapter | Simple style |
| 27 | 16:9 | plane | IPS | 3840*2160 | 60 Hertz | 300 Nit | GTG 7 ms(W/ OD) | ADOBE 95% | N/A | N/A | HDMI(2.0)*2)+revealport | adapter | Simple style |
| 27 | 16:9 | plane | IPS | 2560*1440 | 75 Hertz | 300 Nit | GTG 5 ms（W/ OD) | DCI P3 95%,Adobe 95%(CIE 1976),SRGB 99% | 16.7M | N/A | HDMI(1.4)*2+revealport1.2+Audio outputport | adapter | Simple style |
| 27 | 16:9 | plane | IPS | 3840*2160 | 60 Hertz | 300 Nit | GTG 5 ms（W/ OD) | DCI P3 95%,Adobe 95%(CIE 1976),SRGB 99% | 1.07B | N/A | HDMI(1.4)+HDMI(2.0)+revealport1.2+Audio outputport | adapter | Simple style |
| 27 | 16:9 | plane | IPS | 3840*2160 | 60 Hertz | 300/400 Nit | GTG 5 ms（W/ OD) | DCI P3 95%,Adobe 95%(CIE 1976),SRGB 99% | 1.07B | HDR10/ HDR400 | HDMI(2.0)+HDMI(2.0)+revealport(1.2)+Type-C(PD 90W)+Audio outputport | adapter | Simple style |
| 27 | 16:9 | plane | IPS | 2560*1440 | 75 Hertz | 300 Nit | GTG 5 ms（W/ OD) | DCI P3 95%,Adobe 95%(CIE 1976),SRGB 99% | 16.7M | N/A | HDMI(1.4)+revealport1.2+TYPE C(65W)+Audio outputport | Built-in power supply | Height adjustable stand |
| 27 | 16:9 | plane | IPS | 3840*2160 | 60 Hertz | 300 Nit(Up to 400) | GTG 5 ms（W/ OD) | DCI P3 95%,Adobe 95%(CIE 1976),SRGB 99% | 1.07B | HDR 400(Optional) | HDMI(2.0)+revealport1.2+TYPE C(65W)+Audio outputport | Built-in power supply | Height adjustable stand |
| 27 | 16:9 | plane | IPS | 3840*2160 | 60 Hertz | 300 Nit(Up to 400) | GTG 5 ms（W/ OD) | DCI P3 95%,Adobe 95%(CIE 1976),SRGB 99% | 1.07B | HDR 400(Optional) | HDMI(2.0)+revealport1.4+TYPE C(65W)+U2(1U2D)+Audio outputport | Built-in power supply | Height adjustable stand |
| 21.45 | 16:9 | plane | VA | 1920*1080 | 75 Hertz/100 Hertz | 250 Nit | GTG 5 ms（W/ OD) | 72% NTSC | N/A | N/A | ①VGA+HDMIDMI(1.4); ②VGA+HDMIDMI+Audio outputport+megaphone ③VGA+HDMIDMI+revealport+A(I/O)+megaphone ④HDMI+HDMI+revealport+A(I/O)+megaphone;⑤V+DVI+HDMI+revealport+A+USB(1B2A)+megaphone | adapter/Built-in power supply | Simple style |
| 23.8 | 16:9 | plane | VA/IPS | 1920*1080 | 75 Hertz/100 Hertz | 250 Nit | GTG 5 ms（W/ OD) | 72% NTSC | N/A | N/A | ①VGA+HDMIDMI(1.4); ②VGA+HDMIDMI+Audio outputport+megaphone ③VGA+HDMIDMI+revealport+A(I/O)+megaphone ④HDMI+HDMI+revealport+A(I/O)+megaphone;⑤V+DVI+HDMI+revealport+A+USB(1B2A)+megaphone | adapter/Built-in power supply | Simple style |
| 23.8 | 16:9 | plane | IPS | 2560*1440 | 75 Hertz | 250 Nit | GTG 5 ms（W/ OD) | 72% NTSC | N/A | N/A | ①VGA+HDMIDMI(1.4); ②VGA+HDMIDMI+Audio outputport+megaphone ③VGA+HDMIDMI+revealport+A(I/O)+megaphone ④HDMI+HDMI+revealport+A(I/O)+megaphone;⑤V+DVI+HDMI+revealport+A+USB(1B2A)+megaphone | Built-in power supply | Simple style |
| 24.5 | 16:9 | plane | VA/IPS | 1920*1080 | 75 Hertz/100 Hertz | 250 Nit | GTG 5 ms（W/ OD) | 72% NTSC | N/A | N/A | ①VGA+HDMIDMI(1.4); ②VGA+HDMIDMI+Audio outputport+megaphone ③VGA+HDMIDMI+revealport+A(I/O)+megaphone ④HDMI+HDMI+revealport+A(I/O)+megaphone;⑤V+DVI+HDMI+revealport+A+USB(1B2A)+megaphone | Built-in power supply | Simple style |
| 27 | 16:9 | plane | VA/IPS | 1920*1080 | 75 Hertz/100 Hertz | 250 Nit | GTG 5 ms（W/ OD) | 72% NTSC | N/A | N/A | ①VGA+HDMIDMI(1.4); ②VGA+HDMIDMI+Audio outputport+megaphone ③VGA+HDMIDMI+revealport+A(I/O)+megaphone ④HDMI+HDMI+revealport+A(I/O)+megaphone;⑤V+DVI+HDMI+revealport+A+USB(1B2A)+megaphone | adapter/Built-in power supply | Simple style |
| 27 | 16:9 | plane | VA/IPS | 2560*1440 | 75 Hertz | 250 Nit | GTG 5 ms（W/ OD) | 72% NTSC | N/A | N/A | ①VGA+HDMIDMI(1.4); ②VGA+HDMIDMI+Audio outputport+megaphone ③VGA+HDMIDMI+revealport+A(I/O)+megaphone ④HDMI+HDMI+revealport+A(I/O)+megaphone;⑤V+DVI+HDMI+revealport+A+USB(1B2A)+megaphone | adapter/Built-in power supply | Simple style |
| Dimension | Screen scale | Form | Panel type | Resolution | Refresh rate | luminance | Response time | Colour gamut | HDR | Port | Input power supply | Ambient lighting | Stand/Base |
| 23.8 | 16:9 | plane | VA/IPS | 1920*1080 | 165 Hertz | 200 Nit | 1 ms(MPRT),GTG 4 ms | DCI-P3 90% | N/A | HDMI(1.4)+HDMI(1.4)+revealport1.2+Audio outputport | Direct current 12V/3A | N/A | Simple style |
| 27 | 16:9 | plane | VA/IPS | 1920*1080 | 165 Hertz | 300 Nit | 1 ms(MPRT),GTG 4 ms | DCI-P3 90% | N/A | HDMI(1.4)+HDMI(1.4)+revealport1.2+Audio outputport | Direct current 19V/2.54A | N/A | Simple style |
| 27 | 16:9 | plane | VA/IPS | 2560*1440 | 144 Hertz | 300 Nit | 1 ms(MPRT),GTG 4 ms | DCI-P3 90% | N/A | HDMI(2.0)+HDMI(1.4)+revealport1.2+Audio outputport | Direct current 19V/2.54A | N/A | Simple style |
| 23.8 | 16:9 | plane | FAST IPS/VA | 1920*1080 | 165 Hertz | 300 Nit | 1 ms(MPRT),GTG 4 ms | DCI-P3 90% | N/A | HDMI(1.4)*2+revealport1.2+Audio outputport | Direct current 12V/2.5A | N/A | Simple style |
| 27 | 16:9 | plane | FAST IPS/VA | 1920*1080 | 165 Hertz | 300 Nit | 1 ms(MPRT),GTG 1 ms | DCI-P3 90% | N/A | HDMI(1.4)*2+revealport1.2+Audio outputport | Direct current 12V/2.5A | N/A | Simple style |
| 27 | 16:9 | plane | FAST IPS/VA | 1920*1080 | 240 Hertz | 300 Nit | 1 ms(MPRT),GTG 1 ms | DCI-P3 90% | N/A | HDMI(1.4)*2+revealport1.2+Audio outputport | Direct current 12V/2.5A | N/A | Simple style |
| 27 | 16:9 | plane | FAST IPS/VA | 2560*1440 | 165 Hertz | 400 Nit | 1 ms(MPRT),GTG 1 ms | DCI-P3 90% | HDR400 | HDMI(2.0)*2+revealport1.2+Audio outputport | Direct current 12V/2.5A | N/A | Simple style |
| 27 | 16:9 | plane | VA | 2560*1440 | 240 Hertz | 400 Nit | 1 ms(MPRT),GTG 1 ms | DCI-P3 90% | HDR400 | HDMI(2.0)*2+revealport1.2+Audio outputport | Direct current 12V/2.5A | N/A | Simple style |
| 27 | 16:9 | plane | IPS | 1920*1080 | 165 Hertz | 250 Nit | 1 ms(MPRT),GTG 7 ms | DCI-P3 90%, Adobe 95%(CIE 1976), SRGB 99% | N/A | HDMI(1.4)*2+revealport1.2+Audio outputport | Direct current 19V/2.58A | N/A | Simple style |
| 27 | 16:9 | plane | IPS | 2560*1440 | 144 Hertz | 250 Nit | 1 ms(MPRT),GTG 2 ms | DCI-P3 90%, Adobe 95%(CIE 1976), SRGB 99% | N/A | HDMI(1.4)+HDMI(2.0)+revealport1.2+Audio outputport | Direct current 19V/2.58A | N/A | Simple style |
| 27 | 16:9 | plane | IPS | 1920*1080 | 165 Hertz | 250 Nit | 1 ms(MPRT),GTG 4 ms | DCI-P3 90% | N/A | HDMI(1.4)+DP1.2+TYPEC C(15W)+A/O | Direct current 19V/2.58A | N/A | Height adjustable stand |
| 27 | 16:9 | plane | Fast IPS | 2560*1440 | 165 Hertz | 400 Nit | GTG 1 ms | DCI-P3 90% | HDR400 | HDMI(2.0)*2+revealport1.2+Audio outputport口 | Direct current 19V/3.52A | N/A | Height adjustable stand |
| 27 | 16:9 | plane | IPS | 1920*1080 | 165 Hertz | 300 Nit | 1 ms(MPRT), GTG 4 ms | DCI-P3 90% | N/A | HDMI(1.4)*2+revealport1.2+Audio outputport | Built-in power supply | RGB LED | Height adjustable stand |
| 27 | 16:9 | plane | IPS | 1920*1080 | 240 Hertz | 300 Nit | 1 ms(MPRT), GTG 4 ms | DCI-P3 90% | N/A | HDMI(2.0)+HDMI(1.4)+revealport1.2+Audio outputport | Built-in power supply | RGB LED | Height adjustable stand |
| 27 | 16:9 | plane | Fast IPS | 2560*1440 | 165 Hertz | 300 Nit | 1 ms(MPRT), GTG 1 ms | DCI-P3 90% | N/A | HDMI(2.0)+HDMI(1.4)+revealport1.2+Audio outputport | Built-in power supply | RGB LED | Height adjustable stand |
| 27 | 16:9 | plane | Fast IPS | 2560*1440 | 170 Hertz | 400 Nit | 1 ms(MPRT), GTG 1 ms | DCI-P3 90% | N/A | HDMI(2.0)+HDMI(1.4)+revealport1.2+Audio outputport | Built-in power supply | RGB LED | Height adjustable stand |
| 27 | 16:9 | plane | Fast IPS | 2560*1440 | 240 Hertz | 400 Nit | 1 ms(MPRT), GTG 1 ms | DCI-P3 90% | N/A | HDMI(2.0)+HDMI(1.4)+revealport1.2+Audio outputport | Built-in power supply | RGB LED | Height adjustable stand |
| 27 | 16:9 | plane | IPS | 1920*1080 | 65 Hertz/180 Hertz/240 Hertz | 300 Nit | 1 ms(MPRT), GTG 4 ms | DCI-P3 90% | N/A | HDMI(2.0)*2+revealport1.2+Audio outputport | Built-in power supply | RGB LED | Height adjustable stand |
| 27 | 16:9 | plane | Fast IPS | 2560*1440 | 170 Hertz / 240 Hertz | 400 Nit | 1 ms(MPRT), GTG 1 ms | DCI-P3 90% | N/A | HDMI(2.0)*2+revealport1.4+Audio outputport | Built-in power supply | RGB LED | Height adjustable stand |
| 27 | 16:9 | plane | Fast IPS | 2560*1440 | 160 Hertz | 400 Nit | 1 ms(MPRT), GTG 1 ms | DCI-P3 90% | N/A | HDMI(2.1)*2+revealport1.4+Audio outputport | Built-in power supply | RGB LED | Height adjustable stand |
| 27 | 16:9 | plane | Fast IPS | 1920*1080 | 165 Hertz/180 Hertz/240 Hertz | 400 Nit | 1 ms(MPRT), GTG 1 ms | DCI-P3 90% | N/A | HDMI(2.0)*2+revealport1.2+Audio outputport | Built-in power supply | RGB LED | Height adjustable stand |
| 27 | 16:9 | plane | Fast IPS | 2560*1440 | 170 Hertz / 240 Hertz | 400 Nit | 1 ms(MPRT), GTG 1 ms | DCI-P3 90% | N/A | HDMI(2.0)*2+revealport1.2+Audio outputport | Built-in power supply | RGB LED | Height adjustable stand |
| 39.5 | 21:9 | plane | IPS | 3440*1440 | 144 Hertz (The highest 155 Hertz OD) | 400 Nit(TYP) | 1 ms(MPRT), GTG 4 ms | DCI-P3 90% | HDR400 | ①HDM+HDM+revealport+USB C(65W)+Audio outputport ②HDM+HDM+revealport+USB C(65W)+USB HUB(2.0)+Audio outputport | Built-in power supply | RGB LED | Simple style |
| Dimension | Screen scale | Curvature | Panel type | Resolution | Refresh rate | luminance | Response time | Colour gamut | HDR | Port | Input power supply | Ambient lighting | Stand/Base |
| 27 | 16:9 | R1500 | VA | 1920*1080 | 165 Hertz | 200 Nit | 1 ms(MPRT), GTG 4 ms | DCI-P3 90% | N/A | HDMI(1.4)*2+revealport1.2+Audio outputport | Direct current 19V/2.58A | N/A | Simple style/Height adjustable stand |
| 27 | 16:9 | R1500 | VA | 1920*1080 | 240 Hertz | 250 Nit | 1 ms(MPRT), GTG 4 ms | DCI-P3 90% | N/A | HDMI(1.4)*2+revealport1.2+Audio outputport | Direct current 19V/2.58A | N/A | Simple style/Height adjustable stand |
| 27 | 16:9 | R1500 | VA | 2560*1440 | 165 Hertz | 300 Nit | 1 ms(MPRT), GTG 4 ms | DCI-P3 90% | HDR10 | HDMI(2.0*2+revealport1.2+Audio outputport | Direct current 19V/2.58A | N/A | Simple style/Height adjustable stand |
| 27 | 16:9 | R1000 | VA | 2560*1440 | 170 Hertz / 240 Hertz | 300 Nit | 1 ms(MPRT), GTG 4 ms | DCI-P3 90% | N/A | HDMI(1.4)+HDMI(2.0)+revealport1.2+Audio outputport | Built-in power supply | RGB LED | Height adjustable stand |
| 31.5 | 16:9 | R1000 | VA | 2560*1440 | 170 Hertz | 300 Nit | 1 ms(MPRT), GTG 4 ms | DCI-P3 90% | N/A | HDMI(2.0)+HDMI(1.4)+revealport1.2+Audio outputport | Built-in power supply | RGB LED | Height adjustable stand |
| 34 | 21:9 | R1500 | VA | 3440*1440 | 165 Hertz | 300 / 400 Nit | 1 ms(MPRT), GTG 4 ms | DCI-P3 90% | HDR10 | HDMI(2.0*2+revealport1.2+Audio outputport | Direct current 19V/3.42A | RGB LED(Optional) | Height adjustable stand |
| 34 | 21:9 | R1000 | VA | 3440*1440 | 165 Hertz | 300 / 400 Nit | 1 ms(MPRT), GTG 4 ms | DCI-P3 90% | HDR10 | HDMI(2.0*2+revealport1.2+U3(1U2D)+Audio outputport | communication 110-220V | RGB LED | Height adjustable stand |
| 49 | 21:9 | R1500 | VA | DFHD 3840*1080 | 144 Hertz | 400 Nit | 1 ms(MPRT), GTG 4 ms | DCI-P3 90% | HDR400 | HDMI(2.0*2+revealport1.2+U3(1U2D)+Audio outputport | Ac input | RGB LED | Simple style |
| Dimension | Screen scale | Form | Panel type | Resolution | Refresh rate | luminance | Response time | Colour gamut | HDR | Port | Input power supply | Stand/Base |
| 15.6 | 16:9 | plane | IPS | 1920*1080 | 60 Hertz | 200 Nit | GTG 5 ms | NTSC 45% | N/A | megaphone : 8ꭥ1W*2 | TYPE C*2+mini HDMI1 | Simple style |
| 15.6 | 16:9 | plane | OLED | 1920*1080 | 60 Hertz | 400 Nit | 1ms | DCI P3 99% | N/A | megaphone : 8ꭥ1W*2 | TYPE C*2+mini HDMI1 | Simple style |
| 15.6 | 16:9 | plane | ISP | 1920*1080 | 60 Hertz | 200 Nit | GTG 5 ms | NTSC 72% | N/A | megaphone : 8ꭥ1W*2 | TYPE C*2+mini HDMI1 | Simple style |
* Product in kind shall prevail. Parameters and specifications are subject to change without prior notice
